Binary Classification Using PyTorch, Part 1: New Best Practices

Because machine learning with deep neural techniques has advanced quickly, our resident data scientist updates binary classification techniques and best practices based on experience over the past two years.

A binary classification problem is one where the goal is to predict a discrete value where there are just two possibilities. For example, you might want to predict the gender (male or female) of a person based on their age, state where they live, annual income and political leaning (conservative, moderate, liberal).

Previous articles in Visual Studio Magazine have explained binary classification using PyTorch. But machine learning with deep neural techniques has advanced quickly. This article updates binary classification techniques and best practices based on experience over the past two years.

A good way to see where this article is headed is to take a look at the screenshot of a demo program in Figure 1. The demo begins by loading a 200-item file of training data and a 40-item set of test data. Each tab-delimited line represents a person. The fields are gender (male = 0, female = 1), age, state of residence, annual income and politics type. The goal is to predict gender from age, state, income and political leaning.

Figure 1: Binary Classification Using PyTorch Demo Run
[Click on image for larger view.] Figure 1: Binary Classification Using PyTorch Demo Run

After the training data is loaded into memory, the demo creates an 8-(10-10)-1 neural network. This means there are eight input nodes, two hidden neural layers with 10 nodes each and one output node.

The demo prepares to train the network by setting a batch size of 10, stochastic gradient descent (SGD) optimization with a learning rate of 0.01, and maximum training epochs of 500 passes through the training data. The meaning of these values and how they are determined will be explained shortly.

The demo program monitors training by computing and displaying loss values. The loss values slowly decrease, which indicates that training is probably succeeding. The magnitude of the loss values isn't directly interpretable; the important thing is that the loss decreases.

After 500 training epochs, the demo program computes the accuracy of the trained model on the training data as 82.50 percent (165 out of 200 correct). The model accuracy on the test data is 85.00 percent (34 out of 40 correct). For binary classification models, in addition to accuracy, it's standard practice to compute additional metrics: precision, recall and F1 score.

After evaluating the trained network, the demo saves the trained model to file so that it can be used without having to retrain the network from scratch. There are two main ways to save a PyTorch model. The demo uses the save-state approach.

After saving the model, the demo predicts the gender for a person who is 30 years old, from Oklahoma, who makes $40,000 annually and is politically moderate. The raw prediction is 0.3193. This value is a pseudo-probability where values less than 0.5 indicate class 0 (male) and values greater than 0.5 indicate class 1 (female). Therefore the prediction is male.

This article assumes you have a basic familiarity with Python and intermediate or better experience with a C-family language but does not assume you know much about PyTorch or neural networks. The complete demo program source code and data can be found here.

Installing PyTorch
The demo program was developed on a Windows 10/11 machine using the Anaconda 2020.02 64-bit distribution (which contains Python 3.7.6) and PyTorch version 1.12.1 for CPU. Installing PyTorch is like driving a car -- relatively easy once you know how but difficult if you haven't done it before.

I work at a large tech company, and one of my job responsibilities is to deliver training classes to software engineers and data scientists. By far the biggest hurdle for people who are new to PyTorch is installation.

There are dozens of different ways to install PyTorch on Windows. The configuration I strongly recommend for beginners is to use the Anaconda distribution of Python and install PyTorch using the pip package manager. The Anaconda distribution of Python contains a base Python engine plus over 500 add-in packages that have been tested to be compatible with one another.

After you have a Python distribution installed, you can install PyTorch in several different ways. I recommend using the pip utility, which is installed as part of Anaconda. Briefly, you download a .whl ("wheel") file to your local machine, open a command shell and issue the command "pip install (whl-file-name)."

I have published detailed step-by-step instructions for installing Anaconda Python for Windows 10/11 and detailed instructions for downloading and installing PyTorch 1.12.1 for Python 3.7.6 on a Windows CPU machine.

Preparing the Data
The raw demo data looks like:

F   24   michigan   29500.00   liberal
M   39   oklahoma   51200.00   moderate
F   63   nebraska   75800.00   conservative
M   36   michigan   44500.00   moderate
. . .

There are 240 lines of data. Each line represents a person. The five fields are sex (M, F), age, state of residence (Michigan, Nebraska, Oklahoma), annual income and politics type (conservative, moderate, liberal). The data is artificial. The raw data was split into a 200-item set for training and a 40-item set for testing.

The raw data must be encoded and normalized. The result is:

1   0.24   1   0   0   0.2950   0  0  1
0   0.39   0   0   1   0.5120   0  1  0
1   0.63   0   1   0   0.7580   1  0  0
0   0.36   1   0   0   0.4450   0  1  0
. . .

The variable to predict (often called the class or the label) is gender, which has possible values of male or female. For PyTorch binary classification, you should encode the variable to predict using 0-1 encoding. The demo sets male = 0, female = 1. The order of the encoding is arbitrary.

Because neural networks only understand numbers, the state and political leaning predictor values (often called features in neural network terminology) must be encoded. The state values are one-hot encoded as Michigan = (1 0 0), Nebraska = (0 1 0) and Oklahoma = (0 0 1). The order of the encoding is arbitrary. If the state variable had four possible values, then the encodings would be (1 0 0 0), (0 1 0 0) and so on. The political leaning values are one-hot encoded as conservative = (1 0 0), moderate = (0 1 0) and liberal = (0 0 1).

The demo data normalizes the numeric age and annual income values. The age values are divided by 100; for example, age = 24 is normalized to age = 0.24. The income values are divided by 100,000; for example, income = $55,000.00 is normalized to 0.5500. The resulting normalized age and income values are all between 0.0 and 1.0.

The technique of normalizing numeric data by dividing by a constant does not have a standard name. Two other normalization techniques are called min-max normalization and z-score normalization. I recommend using the divide-by-constant technique whenever possible. There is convincing (but currently unpublished) research that indicates divide-by-constant normalization usually gives better results than min-max normalization or z-score normalization. The topic is quite complex. For details, see "Why I Don't Use Min-Max or Z-Score Normalization For Neural Networks."

The demo data does not have any binary predictor variables such as "employed" with possible values yes or no. For binary predictor variables I recommend using minus-one-plus-one encoding rather than 0-1 encoding. In theory both encoding schemes work for binary predictor variables, but in practice minus-one-plus-one encoding often produces a better model. For an explanation, see "Should You Encode Neural Network Binary Predictors as 0 and 1, or as -1 and +1?"

The demo preprocesses the raw data by normalizing numeric values and encoding categorical values. It is possible to normalize and encode training and test data on the fly, but preprocessing is usually a simpler approach.

Overall Program Structure
The overall structure of the demo program is presented in Listing 1. The demo program is named people_gender.py. The program imports the NumPy (numerical Python) library and assigns it an alias of np. The program imports PyTorch and assigns it an alias of T. Most PyTorch programs do not use the T alias but my work colleagues and I often do so to save space. The demo program indents using two spaces rather than the more common four spaces, again to save space.

Listing 1: Overall Program Structure

# people_gender.py
# binary classification
# PyTorch 1.12.1-CPU Anaconda3-2020.02  Python 3.7.6
# Windows 10/11

import numpy as np
import torch as T
device = T.device('cpu')

class PeopleDataset(T.utils.data.Dataset): . . .

class Net(T.nn.Module): . . .

def metrics(model, ds, thresh=0.5): . . .

def main():
  # 0. get started
  print("People gender using PyTorch ")
  T.manual_seed(1)
  np.random.seed(1)

  # 1. create Dataset objects
  # 2. create network
  # 3. train model
  # 4. evaluate model accuracy
  # 5. save model (state_dict approach)
  # 6. make a prediction

  print("End People binary classification demo ")

if __name__ == "__main__":
  main()

The global device is set to "cpu." If you are working with a machine that has a GPU processor, the device string is "cuda." Most of my colleagues and I develop neural networks on a local CPU machine, then if necessary (huge amount of training data or huge neural network), push the program to a GPU machine and train it there.

The demo has a program-defined PeopleDataset class that stores training and test data. The data in a Dataset object can be served up in batches for training by using the built-in DataLoader object. It is possible to use training and test data directly instead of using a Dataset, but such problem scenarios are rare and you should use a Dataset for most problems.

The binary neural network classifier is implemented in a program-defined Net class. The Net class inherits from the built-in torch.nn.Module class, which supplies most of the neural network functionality. Instead of using a class to define a PyTorch neural network, it is possible to create a neural network directly using the torch.nn.Sequential class. Using Sequential is simpler but less flexible than using a program-defined class. The fact that there are two completely different ways to define a PyTorch neural network can be confusing for beginners.

In a neural network binary classification problem, you must implement a program-defined function to compute classification accuracy of the trained model. The demo program defines a metrics() function that accepts a network and a Dataset object.

All of the demo program control logic is contained in a program-defined main() function. The demo program begins by setting the seed values for the NumPy random number generator and the PyTorch generator. Setting seed values is helpful so that demo runs are mostly reproducible. However, when working with complex neural networks such as Transformer networks, exact reproducibility cannot always be guaranteed because of separate threads of execution.

The Dataset Definition
The demo Dataset definition is presented in Listing 2. A Dataset inherits from the torch.utils.data.Dataset class, and you must implement three methods:

  • __init__(), which loads the data from file into memory as PyTorch tensors
  • __len__(), which tells the DataLoader object that uses the Dataset how many items there so that the DataLoader knows when all items have been processed during training
  • __getitem__(), which returns a single data item, rather than a batch of items as you might have expected

Listing 2: Dataset Definition

class PeopleDataset(T.utils.data.Dataset):
  # like 0   0.27   0 1 0   0.7610   1 0 0
  def __init__(self, src_file):
    all_data = np.loadtxt(src_file, usecols=range(0,9),
      delimiter="\t", comments="#", dtype=np.float32)

    self.x_data = T.tensor(all_data[:,1:9],
      dtype=T.float32).to(device)
    self.y_data = T.tensor(all_data[:,0],
      dtype=T.float32).to(device)  # float32 required

    self.y_data = self.y_data.reshape(-1,1)  # 2-D required

  def __len__(self):
    return len(self.x_data)

  def __getitem__(self, idx):
    feats = self.x_data[idx,:]  # idx row, all 8 cols
    sex = self.y_data[idx,:]    # idx row, the only col
    return feats, sex  # as a Tuple

Defining a PyTorch Dataset is not trivial. You must define a custom Dataset for each problem/data scenario. The __init__() method accepts a src_file parameter that tells the Dataset where the file of training data is located. The entire file is read into memory as a NumPy two-dimensional array using the NumPy loadtxt() function. Commonly used alternatives include the NumPy genfromtxt() function and the Pandas read_csv() function.

The call to loadtxt() specifies argument comments="#" to indicate that lines beginning with "#" are comments and should be ignored. The "#" character is the default for comments and so the argument could have been omitted.

The syntax all_xy[:,1:9] means all rows in matrix all_xy, columns [1] to [8] inclusive. The syntax all_xy[:,0] means all rows, just column [0]. The data is read in as type float32, which is the default data type for PyTorch predictor values.

The data is converted from NumPy arrays to PyTorch tensors. Notice that the class labels-to-predict in self.y_data are type float32 rather than type int64 as you might expect. This is required for binary classification. The self.y_data one-dimension vector must be reshaped to a two-dimensional form. The reshape(-1,1) syntax means "all batch rows." Dealing with PyTorch vector and matrix shapes can be extremely time-consuming during development.

The self.x_data and self.y_data are loaded into memory using the .to(device) method, which in this case is "cpu." Because the default device type for a newly created PyTorch Tensor object is None, it's good practice to explicitly use .to(device) whenever a new Tensor is instantiated.

The __len__() function returns the number of rows in the self.x_data Tensor matrix. You could also use len(self.y_data) because the self.y_data vector has the same number of values.

The __getitem__() method accepts an index parameter, idx. The predictor values for item [idx] are pulled from self.x_data using normal array indexing. The class labels are also pulled using normal indexing syntax. The return value is a Python Tuple object where a set of predictors values is at tuple position [0] and the single associated class label is at tuple position [1].

An alternative approach is to return the predictors and label as a Python Dictionary object. That code would look like:

def __getitem__(self, idx):
  feats = self.x_data[idx,:]
  sex = self.y_data[idx,:]
  sample = { 'predictors' : feats, 'targets' : sex }
  return sample  # as Dictionary

The Dictionary approach allows you to access predictors and labels by name rather than by indexing. However, the Dictionary approach creates "magic strings" and so the Tuple approach is more common.

The demo Dataset definition assumes that the predictor values and the class labels are in the same source file. In some situations, the predictors and label are defined in separate files. In such situations you must pass two file paths instead of just one to the __init__() method.

A Dataset must be able to store all data in memory. This usually isn't a problem. But for huge sets of data, you must create a streaming data loader. This is very difficult. See "How To: Create a Streaming Data Loader for PyTorch" for an example.

Defining the Network
The neural network definition is presented in Listing 3. The network architecture is 8-(10-10)-1 with tanh() hidden node activation. The number of input nodes for a binary classifier is determined by the training data. There is always one output node. The number of hidden layers and the number of nodes in each layer are hyperparameters that must be determined by trial and error.

The __init__() method sets up the layers and optionally specifies how to initialize the layer weights and biases. The demo uses explicit initialization, but it's more common to use default weight and bias initialization. Weight and bias initialization is a surprisingly complex topic, and the documentation on the topic is a weak point of PyTorch. The choice of initialization algorithm often has a large effect on the behavior of a neural network.

The advantage of using default weight and bias initialization is simplicity. The disadvantage is that the default initialization algorithm can, and has, changed several times. My recommendation is to use explicit weight and bias initialization for simple binary classifiers with just one or two hidden layers, but use default initialization for classifiers with three or more hidden layers.

Listing 3: Neural Network Class Definition

class Net(T.nn.Module):
  def __init__(self):
    super(Net, self).__init__()
    self.hid1 = T.nn.Linear(8, 10)  # 8-(10-10)-1
    self.hid2 = T.nn.Linear(10, 10)
    self.oupt = T.nn.Linear(10, 1)

    T.nn.init.xavier_uniform_(self.hid1.weight)
    T.nn.init.zeros_(self.hid1.bias)
    T.nn.init.xavier_uniform_(self.hid2.weight)
    T.nn.init.zeros_(self.hid2.bias)
    T.nn.init.xavier_uniform_(self.oupt.weight)
    T.nn.init.zeros_(self.oupt.bias)

  def forward(self, x):
    z = T.tanh(self.hid1(x))
    z = T.tanh(self.hid2(z))
    z = T.sigmoid(self.oupt(z))  # for BCELoss()
    return z

The demo network uses tanh() activation on the hidden nodes. In the early days of neural networks, sigmoid() hidden layer activation was common, but it's now rarely used. For deep neural networks, relu() activation is often used. There are essentially no good rules of thumb for deciding which hidden layer activation to use. It's a good idea to try both tanh() and relu() and see which seems to work better in combination with all your other hyperparameters.

A common source of confusion for those who are new to PyTorch binary classification is the output layer activation function. There is a strong coupling between output activation and the loss function used during training. The demo program uses sigmoid() output layer activation. This approach assumes that you use BCELoss() ("binary cross entropy loss") during training. The underlying theory and mechanics of output activation and loss function are complex, but you don't need to fully understand them to create a binary classifier -- just use sigmoid() activation on the output node and use BCELoss() during training.

The network dimensions of 8, 10, 10, 1 are hard-coded. It is possible to pass these values as parameters to the __init__() function, but the hard-coded approach is simpler and easier to understand, which trumps the minor loss of flexibility in my opinion.

Wrapping Up
The demo code presented in this article can be used as a guide to prepare training data and as a template to define a neural network for most binary classification problems. Part 2 will explain how to train the network, compute the trained network's classification accuracy, save the network for use by other programs and use the network to make predictions.
